MacDon D1 Series - 118162 Clip - Hold-Down; 18654 Nut - Hex 7;16 NC GR5 ZP; 118154 Bolt - HH 3;8 NC X 5;8 TFL GR8 ZP; 118193 Nut - Flange Hex.375 NC

215184 501 Revision A
Figure 12.1: Bag A - Cutterbar Components
1009800
A
B
C
D
E
F
G
J
H
A - 118344 – Knife Guard B - 118162 – Clip - Hold-Down
C - 18654 – Nut - Hex 7/16 NC GR5 ZP D - 118154 – Bolt - HH 3/8 NC X 5/8 TFL GR8 ZP
E - 118193 – Nut - Flange Hex .375 NC F - 120558 – Bolt
G - 125418 – Support - Split C-Bar Connection Weldt H - 129297 – Wearplate - Cutterbar
J - 118345 – Knife Guard
