MacDon D1 Series - Page 524

215184 500 Revision A
Table 12.1 Bagged Parts List for 12.2 and 13.7 m (40 and 45 Ft) Headers (continued)
Part #
Description
Quantity
12.2 m
(40 ft.)
13.7 m
(45 ft.)
105135
Screw – Machine
17 17
50186
Nut – Flange Lock SM Face DT 0.500-13UNC GR5
28 28
Bag D – Reel Arm and Reel Linkage Parts (Hardware in Bag B)
137298
Arm – Cam Control Linkage Sub-Assy
55
137699
USS Hardened Flat Washer – 1/2 NOM. ID
55
50186
Nut – Flange Lock SM Face DT 0.500-13UNC GR5
55
Bag E – Reel Endshields
164958
Support – Endshield Reel
5
10 10
135157
Screw – Machine
10 10
30228
Nut
10 10
105136
Screw – Machine
10 10
50186
Nut – Flange Lock SM Face DT 0.500-13UNC GR5
10 10
137529
Shim – Crank Bearing
10 10
105141
Bolt – Locking Shoulder
10 10
245001
Label – Dealers Only
11
Reel Drive To Center Tube Hardware and Reel Drive Alignment Shims (Parts in Bag B)
18638
Washer – REG Lock 1/2 IN NOM ID ZP
88
21491
Bolt – HH 1/2 NC X 1.25 LG GR 5 ZP
88
164061
Shim – Hub to Cam
22
137753
Shim Ring – 4 Bolt Flange
22
245199
Shim – Hub to Cam
22
Right Skid Shoe if Required (Secured to Header Frame)
172172
Assy – Right, Shoe
11
Parts for Transport after Assembly at Export Destination (Loose Parts in Bag B)
172535
Angle – Guard Tip Shipping
33
REFERENCE
5. Not included for European-configured 12.2 m (40-foot) headers.
