8.2 Checking Wheel Bolt Torque – Transport and Stabilizer Wheels
Perform the following procedure to ensure that transport and stabilizer wheel bolts are correctly torqued:
1001277
2
3
4
5
6
1
Figure 8.1: Sequence for Tightening Bolts
1. Check that wheel bolt torque is 110–120 Nm (80–90 lbf·ft).
2. If necessary, adjust torque. Refer to bolt tightening
sequence illustration at right.
