MacDon D1 Series - Page 251

215184 227 Revision A
1024057
A
B
C
D
Figure 7.54: Driveline
18. Detach safety chain (C) from support bracket (B).
19. Pull collar (D) back to release driveline (A) from support
bracket. Remove the driveline from the support bracket.
1001516
A
Figure 7.55: Driveline and Output Shaft
20. Attach driveline (A) to the combine output shaft.
ATTACHING HEADER TO COMBINE
