MacDon D1 Series - Page 38

215184 14 Revision A
1008293
A
Figure 2.18: Split-Frame Header
1008294
B
C
A
Figure 2.19: Double-Reel Header
A - Attachment Points B - 1100 mm (43 in.)
C - 1500 mm (59 in.)
UNLOADING THE HEADER
