215184 395 Revision A
Figure 9.203: Combine Auto Header Height Controls
1. Press AUTO MODE button (A) until AHHC LED light (B) begins flashing. If the RTC light is flashing, press AUTO MODE
button (A) again until it switches to AHHC.
WARNING
Check to be sure all bystanders have cleared the area.
Figure 9.204: Control Handle
2. Briefly press button (A) on the control handle. The AHHC
light should change from flashing to solid. The header also
should drop toward the ground. The AHHC is now engaged
and can be adjusted for height and sensitivity.
3. Use controls to adjust height and sensitivity to changing
ground conditions such as shallow gullies and field drainage
trenches.
SETTING UP AUTO HEADER HEIGHT CONTROL
