Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Chapter 11 160
A file also contains header parameters that you can define to better describe the
content of the file. You can define notes in the file, and associate up to four notes to an
ID or to a range of IDs. In the file, you can organize the ID range, select the data
format, and select the saved data. Table 10 on page 160 summarizes the contents of a
file and indicates where you can find more information.
You can identify the datalogger parameters in the ID bar at the top of the
measurement screen (see Figure 11-2 on page 161).
Table 10 File contents summary
Contents Description See section
Header Extra parameters to describe the contents and
the context of the data
“Creating a
Data File” on
page 163
Measurement
data
Organized by predefined IDs arranged by file
types
“Data File
Types” on
page 165
Data format defined by the file data mode “File Data
Modes” on
page 182
Saved data (thickness measurement with or
without the waveform) configured using the
setup menu
“Saving
Data” on
page 76
Notes Centralized in a note table “Notes” on
page 192
Associated to an ID or to a range of IDs “Associating
a Note to an
ID or to a
Range of
IDs” on
page 193

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
