Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger 177
associated with the third dimension of the grid (for example, the points). This scenario
allows multiple readings to be stored at each grid coordinate. The example shown in
Table 15 on page 175 assumes that you chose to increment the point first, the row
second and the column third.
To create a 3-D grid data file
1. From the measurement screen, press [FILE], and then select CREATE in the menu
(see “Creating a Data File” on page 163 for details on the first parameters).
2. At the bottom of the CREATE screen, select CONTINUE.
3. In the second page of the CREATE screen (see Figure 11-12 on page 178):
a) Enter the START COLUMN, END COLUMN, START ROW, END ROW,
START POINT, and END POINT values.
b) In INC 1ST BY, select which parameter increments first (POINT, ROW, or
COLUMN).
c) In INC 2ND BY, select which parameter increments second (POINT, ROW, or
COLUMN).
d) Select CREATE.
Table 16 Resulting ID example for the 3‑D GRID file type
Parameters Va lu es Resulting IDs
Start column
End column
Start row
End row
Start point
End point
A
F
1
4
X
Z
A1X
A1Y
A1Z
A2X
...
A4Z
B1X
B1Y
...
AF4Z

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
