Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger 195
To prevent loss of data, do not delete notes of letter codes that have already been
associated with an ID or with a range of IDs. This would destroy the meaning of the
letter codes stored with IDs.
To delete a note from a file
1. Open the file in which you want to delete a note (see “Opening a File” on
page 184).
2. Press [2nd F], [ID#] (NOTE).
3. In the FILE NOTES screen:
a) Select the letter code for the note that you wish to delete.
b) Press the [] key to enter the edit mode.
c) Delete all the characters of the note text.
d) Select SAVE to save the edited note list to the file.
11.4.4 Copying a Note Table
You can easily copy notes from one file to another file in the 38DL PLUS. This is very
useful when you are creating files from the 38DL PLUS and want to use a common
note table.
To prevent loss of data, do not copy a note table to a file that has existing stored letter
codes. Copying would redefine the meaning of existing stored notes.
For example, if A = HOT SURFACES in the original note table, and you copy a note
table where A = PAINTED SURFACES, this changes the definition of A, and thus
changes the meaning of any previously stored A notes.
CAUTION
CAUTION

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
