Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger 189
To delete a file stored in the 38DL PLUS
1. From the measurement screen, press [FILE].
2. In the menu, select DELETE.
3. In the DELETE screen (see Figure 11-20 on page 189):
a) In the list, select one or more files to delete.
A check mark appears on the right on the line of files that you selected.
b) Press [2nd F], [] to leave the list.
c) Select the desired Delete Stored Data or Entire File option.
d) Set DELETE MODE to DATA to only delete the contents of the file.
OR
Set DELETE MODE to FILE to completely erase the file from the memory.
e) Select DELETE to perform the operation.
Figure 11‑20 Deleting a file
When you select to delete multiple files, and some files are delete-protected, the
38DL PLUS will only delete the files that are not delete-protected.
NOTE

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
