DMTA-10004-01EN, Rev. D, November 2016
Using Advanced Gaging Features
157
d) Set TEMP COEFFICIENT to the desired value (typically –0.00018 for °C or –
0.00010 for °F) for steel.
e) Set CURRENT TEMP to the temperature of the actual test piece.
You can specify a negative sign using the [] or [] keys to move the cursor over the
“+” or “–”, and then using the [] and [] keys to change the sign.
Figure 1018 The TEMP COMP screen
4. Press [MEAS] to return to the measurement screen with the activated
temperature compensation (see Figure 10-19 on page 158).
The measured thickness is temperature-compensated based on the
CALIBRATION TEMP, the CURRENT TEMP, and the TEMP COEFFICIENT
parameter values.
NOTE
