DMTA-10004-01EN, Rev. D, November 2016
Chapter 10
158
Figure 10‑19 Displaying temperature compensation data
5. While the temperature compensation function is active, if the temperature of the
test piece changes, you can quickly change the CURRENT TEMP as follows:
a) Press [2nd F], [XDCR RECALL] (REF VALUE).
b) In the CURRENT TEMPERATURE screen, enter the new current
temperature value.
Both the thickness and current temperature values are saved to the internal
datalogger.
