DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger
159
11. Using the Datalogger
This chapter describes how to use the 38DL PLUS internal datalogger to organize
your data.
11.1 Datalogger
The 38DL PLUS datalogger is a file-based system where one file is opened at a time.
The active file stores a measurement at a thickness measurement location ID. Each
time you press [SAVE/SEND], the displayed value is saved to the active file at the
current ID. The ID is automatically incremented for the next measurement. When you
press [FILE], the name of the active file appears in the ID bar above the menu (see
Figure 11-1 on page 159).
Figure 111 The active file name appearing in the ID bar
Name of the active file
