Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Chapter 3 46
7. If you want to cancel the editing operation and return to the original parameter
value, on the virtual keyboard, highlight CANCEL, and then press [ENTER].
8. To complete the editing of the parameter value, on the virtual keyboard, highlight
DONE, and then press [ENTER].
When editing a multiple line parameter value, highlighting DONE and pressing
[ENTER] moves the cursor to the next line. You can also press [2nd F], [] to accept
the text and move the cursor to the next line.
3.4.2 Editing Text Parameters Using the Traditional Method
When the text edit mode is set to TRADITIONAL, you select each character from a
hidden circular list of standard sorted letters, numbers, and special characters (see
Figure 3-8 on page 46). Only upper case letters are available.
Figure 3‑8 The character cycle of the traditional text edit method
NOTE
[]
Cycling begins at “A” when the
original character is a letter
Cycling begins at “0” when the
original character is a digit
[]

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
