DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger
201
Figure 1129 The message when the edited ID is not in the database
7. Press [SAVE/SEND] with or without an active measurement in order for the
edited ID to become a permanent part of the database.
The sequence resumes at the previous active ID.
11.6.3 Erasing Data in the Active File
Data erased by the following techniques CANNOT be recovered.
To erase a single measurement
1. From the measurement screen, press [ID#].
The ID review screen appears and shows the active ID with its stored data.
2. Select the ID to be erased (see “Reviewing Stored Data and Changing the Active
ID” on page 199).
3. Press [2nd F], [FILE] (CLR MEM) to erase the data at the displayed ID.
The displayed ID changes to the next ID in the sequence.
CAUTION

Table of Contents

Other manuals for Olympus 38DL PLUS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus 38DL PLUS and is the answer not in the manual?

Olympus 38DL PLUS Specifications

General IconGeneral
Operating Temperature-10 °C to 50 °C (14 °F to 122 °F)
Data LoggerYes
InterfaceUSB, RS-232
Thickness Range0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
DisplayBacklit LCD
Battery TypeThree alkaline or NiMH AA cells
PulserAdjustable square wave pulser
Receiver Bandwidth0.5 MHz to 20 MHz
LanguagesEnglish, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution0.001 mm or 0.0001 in.
Transducer Frequency2 MHz to 30 MHz
MaterialPlastic housing
