Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger 203
Minimum Review
Allows you to select a file and then review all minimum thickness locations in the
file. You can verify the thickness at all minimum location and replace them if
needed.
To generate a report
1. From the measurement screen, press [FILE].
2. In the menu, select REPORT.
3. In the submenu, select the desired type of report. When you select:
— FILE SUMMARY, go to step 4
— MIN/MAX SUMMARY, go to step 5
— FILE COMPARISON, go to step 6
— ALARM SUMMARY, go to step 7
— MIN REVIEW, go to step 8
4. In the FILE SUMMARY screen (see Figure 11-30 on page 203):
a) Select the file for which you want to create the report.
b) Select REPORT.
The FILE SUMMARY report result screen opens (see Figure 11-31 on
page 204).
Figure 11‑30 The FILE SUMMARY report screen

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
