Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Managing Communications and Data Transfer 259
To view or change the current output file format
1. From the measurement screen, press [SETUP MENU].
2. In the menu, select COMM.
3. In COMM screen, view or change the OUTPUT FORMAT value (see Table 24 on
page 258 and Table 25 on page 259 for a description of the formats).
F8
 
F9
    
F10
 
Table 25 Serial data output format for single element transducers
Format File header ID header
Thickness
table
Wave‑
forms
Setup table Note table
F1

F2
   
F4

F5
   
F6
 
F7
   
F8
 
F9
    
F10
 
Table 24 Serial data output format for dual element transducers (continued)
Format File header ID header
Thickness
table
Wave‑
forms
Setup table Note table

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
