DMTA-10004-01EN, Rev. D, November 2016
Chapter 2
32
2.2 Using the AC Power
You can operate the 38DL PLUS with the AC power using the charger/adaptor (P/N:
EP-MCA [U8767042]). The EP-MCA has a universal AC power input that operates
with any line voltage from 100 VAC to 120 VAC or 200 VAC to 240 VAC and with
50 Hz to 60 Hz line frequency.
To use AC power
1. Connect the AC power cord to the charger/adaptor (P/N: EP-MCA [U8767042]),
and to an appropriate power outlet (see Figure 2-2 on page 32).
To avoid the risk of injuries or equipment damage, use only the AC power cord
supplied with the 38DL PLUS. Do not use this AC power cord with other products.
Figure 2‑2 Connecting the charger/adaptor
2. On the 38DL PLUS, lift the rubber seal covering the DC adaptor connector on top
of the 38DL PLUS (see Figure 2-3 on page 33).
EP-MCA
DC power
plug
AC power cord
