The allowable number of characters for each custom point depends on the ID number
of characters defined in the start and end ID values. The total number of characters of
the ID value plus the custom points cannot exceed 20 characters. For example, when
the start and end ID values are seven characters long, as in the example in Table 14 on
page 169, the maximum allowable length for each custom point is thirteen (20 – 7 =
13).
To create a sequential data file with custom points
1. From the measurement screen, press [FILE], and then select CREATE in the menu
(see “Creating a Data File” on page 163 for details on the first parameters).
2. At the bottom of the CREATE screen, select CONTINUE.
3. In the second page of the CREATE screen (see Figure 11-6 on page 170):
a) Enter the START ID and END ID values.
b) Enter two or more CUSTOM POINTS values.
c) Press [2nd F], [] to finish entering CUSTOM POINTS values.
d) Select CREATE.
Table 14 Resulting ID example for the SEQ+CUSTOM PT file type
START ID END ID Custom points Resulting IDs
XYZ1267 XYZ1393 TOP
BOTTOM
LEFT
RIGHT
XYZ1267TOP
XYZ1267BOTTOM
XYZ1267LEFT
XYZ1267RIGHT
XYZ1268TOP
XYZ1268BOTTOM
XYZ1268LEFT
...
XYZ1393RIGHT

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
