DMTA-10004-01EN, Rev. D, November 2016
Chapter 14
248
If you experience a problem to establish the communication between the 38DL PLUS
and a remote device, consider using the 38DL PLUS communication reset function to
return all communication parameters to the default values (see “Resetting the
Communication Parameters” on page 260) and reconfigure only needed
communication parameters.
14.4 Exchanging Data with a Remote Device
You can exchange 38DL PLUS data with a remote device such as a computer or a
printer.
Data transmitted from the 38DL PLUS remains in the 38DL PLUS internal memory.
14.4.1 Sending Entire Files (RS-232)
You can send a single or multiple files from the 38DL PLUS to a computer or printer.
The data that is transmitted includes the file name, the file header, ID numbers,
thickness data, flags, calibration setups, and notes.
To send entire files from the 38DL PLUS to a computer or printer
1. Ensure that the RS-232 communication parameters are configured correctly (see
“Setting Up RS-232 Serial Communication” on page 245).
2. From the measurement screen, press [FILE].
3. In the menu, select SEND.
4. In the SEND screen (see Figure 14-3 on page 249):
a) Use the [] and [] keys to select to send ALL files or only SELECTED files.
When you select ALL, in the file list, a check mark appears on the right of all
files.
b) When you select SELECTED, you can individually select the files to send:
