Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Chapter 14 244
GageView is compatible with Windows 2000, XP, Vista, and Windows 7. For more
details, refer to the GageView Interface Program — User’s Manual (P/N: 910-259-EN
[U8778347]).
14.2 Setting Up USB Communication
The default communication protocol for the 38DL PLUS is USB 2.0. The 38DL PLUS
can also be set to use RS-232 serial communication (see “Setting Up RS-232 Serial
Communication” on page 245).
To set up the USB communication
1. Ensure that the 38DL PLUS driver is installed on the computer.
This driver is installed when you install the GageView interface program.
For more information on installing GageView, refer to the GageView Interface Program
— User’s Manual (P/N: 910-259-EN [U8778347]).
2. If you use a communication program other than GageView, refer to the program
documentation to properly configure the program for USB communication.
3. Turn the 38DL PLUS on.
4. From the measurement screen, press [SETUP MENU].
5. In the menu, select COMM.
6. In COMM screen, set CONNECTION TYPE to USB.
7. Press [MEAS] to return to the measurement screen.
8. Connect one end of a USB cable to the USB client connector under the I/O door of
the 38DL PLUS, and the other end to a USB port of the computer (see Figure 14-1
on page 245).
NOTE

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
