DMTA-10004-01EN, Rev. D, November 2016
Instrument Description
23
Figure 12 The 38DL PLUS hardware components
1.4 Connectors
Figure 1-3 on page 23 illustrates the possible connections of the 38DL PLUS with
external devices.
Figure 13 The 38DL PLUS connections
Connector rubber seal
Protective rubber boot
(shown in blue)
Stand
Hand strap
Strap rings
(at the four corners)
Color display
Keypad
I/O door protecting more
connectors
Connectors
[ON/OFF] key
USB/RS-232
USB
VGA
Transducer
AC power cord
EP-MCA
microSD

Table of Contents

Other manuals for Olympus 38DL PLUS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus 38DL PLUS and is the answer not in the manual?

Olympus 38DL PLUS Specifications

General IconGeneral
Operating Temperature-10 °C to 50 °C (14 °F to 122 °F)
Data LoggerYes
InterfaceUSB, RS-232
Thickness Range0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
DisplayBacklit LCD
Battery TypeThree alkaline or NiMH AA cells
PulserAdjustable square wave pulser
Receiver Bandwidth0.5 MHz to 20 MHz
LanguagesEnglish, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution0.001 mm or 0.0001 in.
Transducer Frequency2 MHz to 30 MHz
MaterialPlastic housing
