DMTA-10004-01EN, Rev. D, November 2016
Using the Datalogger
199
• Change the current ID location to any location that already exists in the data file
for the purposes of editing that ID location.
11.6.1 Reviewing Stored Data and Changing the Active ID
You use the ID review screen to review the data in the active file.
To review stored data and change the active ID
1. Open the file that you wish to review (see “Opening a File” on page 184).
2. From the measurement screen, press [ID#].
3. While in the ID review screen (see Figure 11-27 on page 198):
a) Review the waveform, status flags, notes, and measured values for the active
ID.
b) Press [] to display the data for the next ID in the file.
c) Press [] to display the data for the previous ID in the file.
d) Press [2nd F], [] and [2nd F], [] to respectively jump to the last ID and to
the first ID in the file.
e) Press [ID#] to edit the ID (see “Editing the ID” on page 199).
4. Press [MEAS] to return to the measurement screen with the new active ID.
11.6.2 Editing the ID
You can edit the ID for one of two following purposes:
• Change the active ID to quickly jump to an existing ID. This is useful when you
are using a large database and it would take too long to locate the desired ID
using the arrow keys.
• Change the active ID to a new ID, which does not yet exist in the file. This mode is
useful when you want to include additional measurement points to the active file.
Additional IDs can be added anywhere in the database (beginning, middle, end).
No stored data is shown while editing the ID.
