Olympus 38DL PLUS User Manual

DMTA-10004-01EN, Rev. D, November 2016
Managing Communications and Data Transfer 253
To import survey files from the external memory card
1. Ensure that the \OlympusNDT\38DLP\Transfer folder on your external
microSD memory card contains the file that you wish to import in the 38DL PLUS
internal memory.
2. Insert the microSD memory card in its slot under the I/O door on the right side of
the 38DL PLUS (see Figure 1-5 on page 25).
3. If you inserted the microSD memory card while the 38DL PLUS was turned on,
turn the 38DL PLUS off, and then back on so that it recognizes the presence of the
memory card.
4. From the measurement screen, press [FILE].
5. In the menu, select IMPORT.
6. In the IMPORT screen (see Figure 14-6 on page 253):
a) Select the file to import in the list of available files.
The listed files are those found in the \OlympusNDT\38DLP\Transfer folder
on the external microSD memory card.
b) Select IMPORT.
c) When a file with the same name already exists in the 38DL PLUS, the
Overwrite existing file? message appears. When you still want to import the
file, select YES.
A beep confirms the end of the file transfer and the instrument returns to the
measurement screen.
Figure 14‑6 Example of the IMPORT screen

Olympus 38DL PLUS Specifications

General

Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Data Logger	Yes
Interface	USB, RS-232
Thickness Range	0.08 mm to 635 mm (0.003 in. to 25 in.) depending on material and transducer
Display	Backlit LCD
Battery Type	Three alkaline or NiMH AA cells
Pulser	Adjustable square wave pulser
Receiver Bandwidth	0.5 MHz to 20 MHz
Languages	English, French, German, Spanish, Italian, Russian, Japanese, Chinese
Resolution	0.001 mm or 0.0001 in.
Transducer Frequency	2 MHz to 30 MHz
Material	Plastic housing
