OM SYSTEM OM-1 Mark II User Manual

Role Function
Live GND Shooting
(GND)
(K only)
Enable the live GND filter (P.246). Press once to enable [Live GND
Shooting] and adjust filter position and boundary settings. Press the
control again to display shooting information and access other settings.
Hold the button and rotate the front or rear dial to adjust [Filter Type]
and [GND Number]. Press and hold the control to select [Off] for [Live
GND Shooting].
Off The control is not used.
Flash Mode (A)
(K only)
Adjust flash settings (P.179). Press once to display flash options and again
select the highlighted option and exit. Highlight settings using the front or
rear dial or HI.
This function can be assigned to the I and G buttons only. You must
first set [d] to [Direct Function].
g/Y
(sequential shooting/
self-timer)
(K only)
Choose a drive (sequential shooting/self-timer) mode (P.190). Press the
button to display drive mode options and then choose a mode using the
front or rear dial or the HI buttons.
This function can be assigned to the I and G buttons only. You must
first set [d] to [Direct Function].
7Lock
(touch control lock)
Lock touch controls. Press and hold the button once to lock touch controls
and again to unlock.
This function can be assigned to the I and G buttons only. You must
first set [d] to [Direct Function].
Electronic Zoom
(X)
Zoom power zoom lenses in or out. After pressing the control, use the
arrow pad to zoom in or out. Use F or I to zoom in and G or H to
zoom out.
This function can be assigned to the I and G buttons only. You must
first set [d] to [Direct Function].
AF Stop (AF Stop)
Suspend autofocus. Focus locks and autofocus is suspended while the
control is pressed. Applies only to the lens j button.
340
Changing the roles of buttons (Button Settings)
C
C
C
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
