2.7 Install the Keypad to a Control Panel or Another Device
36 SIEPCYEUOQ2V01A Q2V Technical Manual
2.7 Install the Keypad to a Control Panel or Another Device
You can remove the keypad from the drive and connect it to a remote control extension cable to make operation
easier when you cannot access the drive. You can operate a drive that is in a control panel without opening or
closing the control panel door. To order optional accessories, contact the manufacturer or your nearest sales
representative.
Name Model Intended Use
Extension Cable
1 m: WV001
3 m: WV003
To connect the keypad and drive.
This option is an RJ-45, 8-pin straight-through UTP CAT5e cable.
Installation Support Set A 900-192-933-001
To attach the keypad to the control panel. This option uses screws.
Installation Support Set B 900-192-933-002
To attach the keypad to the control panel. This option uses nut clamps.
Use this option when weld studs are located in the control panel.
