Omron Q2V Series User Manual

Parameter List
11
11.21 Parameters Changed by PM Motor Code Selection
SIEPCYEUOQ2V01A Q2V Technical Manual 421
11.21 Parameters Changed by PM Motor Code Selection
Note:
The motor codes listed in these tables are the only correct setting values.
◆ Yaskawa SMRA Series SPM Motors
Table 11.5 SMRA Series Motor Code Setting for Specification of 200 V at 1800 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 0002 0003 0005 0006 0008
Voltage Class V 200 200 200 200 200
Capacity kW 0.4 0.75 1.5 2.2 3.7
Motor Rotation Speed min
-1
1800 1800 1800 1800 1800
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7
E5-03
PM Mot Rated Current
(FLA)
A 2.1 4.0 6.9 10.8 17.4
E5-04 PM Mot Pole Count - 8 8 8 8 8
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 2.47 1.02 0.679 0.291 0.169
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 12.7 4.8 3.9 3.6 2.5
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 12.7 4.8 3.9 3.6 2.5
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 0 0 0 0 0
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
62.0 64.1 73.4 69.6 72.2
E1-04 Max Output Frequency Hz 120 120 120 120 120
E1-05 Max Output Voltage V 200.0 200.0 200.0 200.0 200.0
E1-06 Base Frequency Hz 120 120 120 120 120
E1-09 Min Output Frequency Hz 6 6 6 6 6
L3-24 Acc@Rated Torque s 0.064 0.066 0.049 0.051 0.044
n5-02
Mot Inertia Acceleration
Time
s 0.064 0.066 0.049 0.051 0.044
n8-49 Heavy Load Id Current % 0 0 0 0 0
Table 11.6 SMRA Series Motor Code Setting for Specification of 200 V at 3600 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 0103 0105 0106 0108
Voltage Class V 200 200 200 200
Capacity kW 0.75 1.5 2.2 3.7
Motor Rotation Speed min
-1
3600 3600 3600 3600
E5-02 PM Mot Rated Power (kW) kW 0.75 1.5 2.2 3.7
E5-03
PM Mot Rated Current
(FLA)
A 4.1 8.0 10.5 16.5
E5-04 PM Mot Pole Count - 8 8 8 8
E5-05
PM Mot Resistance (Ohms/
Phase)
Ω 0.538 0.20 0.15 0.097
E5-06
PM d-Axis Inductance (mH/
Phase)
mH 3.2 1.3 1.1 1.1
E5-07
PM q-Axis Inductance (mH/
Phase)
mH 3.2 1.3 1.1 1.1
E5-09
PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 0 0 0 0
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/min
-1
32.4 32.7 36.7 39.7
E1-04 Max Output Frequency Hz 240 240 240 240
E1-05 Max Output Voltage V 200.0 200.0 200.0 200.0
