11.6 d: REFERENCE
334 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d4-11
(02B7)
Bi-Dir Out Selection
Sets the function that changes the frequency reference to a Bi-Directional internal
frequency reference.
0 : Disabled
1 : Enabled
0
(0, 1)
520
d4-12
(02B8)
Stop Position Gain
Sets the gain to adjust the stopping accuracy. Set this parameter when b1-03 = 9
[Stopping Method Selection = Distance Stop].
1.00
(0.50 - 2.55)
521
◆ d6: FIELD WEAKENING / FORCING
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d6-01
(02A0)
Field Weak Level
Sets the drive output voltage as a percentage of E1-05 [Field Force Selection] when
H1-xx = 44 [Field weakening] is activated.
80%
(0 - 100%)
522
d6-02
(02A1)
Field Weak FqLimit
Sets the minimum output frequency to start field weakening.
0.0 Hz
(0.0 - 590.0 Hz)
522
d6-03
(02A2)
Field Force Selection
Sets the field forcing function.
0 : Disabled
1 : Enabled
0
(0, 1)
522
d6-06
(02A5)
Field Force Limit
Sets the limit value for field forcing to increase the motor excitation current reference as
a percentage of E2-03 [Mot No-Load Current]. Usually it is not necessary to change
this setting.
400%
(100 - 400%)
522
◆ d7: OFFSET FREQUENCY
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d7-01
(02B2)
RUN
Offset Frq 1
Uses H1-xx = 0E [MFDI Function Select = Offset Frq 1] as a percentage of the
Maximum Output Frequency to add or subtract the set frequency to/from the frequency
reference.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
523
d7-02
(02B3)
RUN
Offset Frq 2
Uses H1-xx = 0F [MFDI Function Select = Offset Frq 2] as a percentage of the
Maximum Output Frequency to add or subtract the set frequency to/from the frequency
reference.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
523
d7-03
(02B4)
RUN
Offset Frq 3
Uses H1-xx = 10 [MFDI Function Select = Offset Frq 3] as a percentage of the
Maximum Output Frequency to add or subtract the set frequency to/from the frequency
reference.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output
frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(-100.0 - +100.0%)
523
