11.8 F: OPTIONS
344 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-55
(03C6)
DNet Baud Monitor
Sets the function to see the actual DeviceNet communications speed using the keypad.
This parameter functions as a monitor only.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
0
(0 - 2)
558
F6-56
(03D7)
DNet Speed Scale Factor
Sets the speed scale for DeviceNet communication.
0
(-15 - +15)
558
F6-57
(03D8)
DNet Current Scale
Factor
Sets the current scale of the DeviceNet communication master.
0
(-15 - +15)
558
F6-58
(03D9)
DNet Torque Scale
Factor
Sets the torque scale of the DeviceNet communication master.
0
(-15 - +15)
558
F6-59
(03DA)
DNet Power Scaling
Sets the power scale of the DeviceNet communication master.
0
(-15 - +15)
558
F6-60
(03DB)
DNet Voltage Scale
Sets the voltage scale of the DeviceNet communication master.
0
(-15 - +15)
558
F6-61
(03DC)
DNet Time Scale
Sets the time scale of the DeviceNet communication master.
0
(-15 - +15)
558
F6-62
(03DD)
DNet Heartbeat Interval
Sets the heartbeat for DeviceNet communication. Set this parameter to 0 to disable the
heartbeat function.
0
(0 - 10)
558
F6-63
(03DE)
DNet Network MAC ID
Sets the function to see the actual DeviceNet MAC address using the keypad. This
parameter functions as a monitor only.
0
(0 - 63)
559
F6-64 to F6-67
(03DF - 03E2)
DynOut.Ass109 P1 to P4
Sets Configurable Outputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
559
F6-68 to F6-71
(03E3, 03E4,
03C7, and
03C8)
DynIn.Ass159 P1 to 4
Sets Configurable Inputs 1 to 4 written to the Modbus register.
0000h
(0000h - FFFFh)
559
F6-72
(081B)
PowerLink Address
Sets the node ID for PowerLink communication.
Note:
Be sure to set an address that is different than all other node addresses. Do not set
this parameter to 0.
0
(0 - 255)
559
F7: ETHERNET
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
Use parameters F7-01 to F7-04 to set the IP Address. Be sure to set a different IP
address for each drive on the network.
Also set parameters F7-01 to F7-12.
192
(0 - 255)
559
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
Use parameters F7-01 to F7-04 to set the IP Address. Be sure to set a different IP
address for each drive on the network.
Also set parameters F7-01 to F7-12.
168
(0 - 255)
559
F7-03
(03E7)
IP Address 3
Sets the third octet of the IP Address for the device that is connecting to the network.
Restart the drive after you change this parameter.
Note:
When F7-13 = 0 [Addr Mode@Startup = Static]:
Use parameters F7-01 to F7-04 to set the IP Address. Be sure to set a different IP
address for each drive on the network.
Also set parameters F7-01 to F7-12.
1
(0 - 255)
559
