11.9 H: TERMINALS
360 SIEPCYEUOQ2V01A Q2V Technical Manual
Setting Value Function Description Ref.
8 TorqRef/Lim
Enters the torque reference if the motor rated torque is 100%. This setting is the torque limit for speed control.
614
9 FW Trq Lim
Enters the forward torque limit if the motor rated torque is 100%.
614
B Rev Trq Lim
Enters the load torque limit if the motor rated torque is 100%.
616
C RegenTrqLim
Enters the regenerative torque limit if the motor rated torque is 100%.
616
D GenerTrqLim
Enters the torque limit that is the same for all quadrants for forward, reverse, and regenerative operation if the
motor rated torque is 100%.
616
E OvUntrq Level
Enters a signal to adjust the overtorque/undertorque detection level.
Note:
Use this function with L6-01 [Torque Detection Selection 1]. This parameter functions as an alternative to L6-
02 [Torque Detection Level 1].
616
F PID Fbk
Enter the PID feedback value as a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
616
10 PID SetPoint
Enters the PID setpoint as a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
616
11 Diff PIDFbk
Enters the PID differential feedback value if the full scale analog signal (10 Vor 20 mA) is 100%.
616
12 AcDcTimeGain
Enters a signal to adjust the gain used for C1-01 to C1-08 [Acceleration/Deceleration Times 1 to 4] and C1-09
[Fast Stop Time] when the full scale analog signal (10 Vor 20 mA) is 100%.
617
13 DCInjBrakCurr
Enters a signal to adjust the current level used for DC Injection Braking when the drive rated output current is
100%.
617
14 StallPLev@Rn
Enters a signal to adjust the stall prevention level during run if the drive rated current is 100%.
617
15 OutFLowLimSel
Enters a signal to adjust the output frequency lower limit level as a percentage of the maximum output frequency.
Note:
Parameter A1-02 [Control Method] selects which parameter is the maximum output frequency.
• A1-02 ≠ 8 [EZ Vector]: E1-04 [Max Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
618
16 Mot PTC Input
Uses the motor Positive Temperature Coefficient (PTC) thermistor to prevent heat damage to the motor as a
percentage of the current value when the 10 V analog signal is input.
618
30 Q2pack AI1
Use with Q2pack. Refer to the Q2pack online manual for more information.
618
31 Q2pack AI2
Use with Q2pack. Refer to the Q2pack online manual for more information.
618
◆ H4: ANALOG OUTPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-01
(041D)
AO An.Out Select
Sets the monitoring number to be output from the MFAO terminal AO.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-01 = 102 to monitor U1-
02 [Output Frequency].
102
(000 - 999)
619
H4-02
(041E)
RUN
AO An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO.
Sets the analog signal output level from the terminal AO at 10 Vor 20 mA as 100%
when an output for monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
619
