11.7 E: MOTOR
338 SIEPCYEUOQ2V01A Q2V Technical Manual
◆ E5: PM MOTOR SETTINGS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E5-01
(0329)
PM Mot Code Selection
Sets the motor code for Yaskawa PM motors. The drive uses the motor code to
automatically set some parameters to their correct settings.
FFFF
(0000 - FFFF)
539
E5-02
(032A)
PM Mot Rated Power
(kW)
Sets the PM motor rated output in the units from o1-58 [Mot Capacity Unit].
Determined by o2-04,
C6-01
(0.10 - 30.00 kW)
539
E5-03
(032B)
PM Mot Rated Current
(FLA)
Sets the PM motor rated current (FLA).
Determined by o2-04,
C6-01
(10% to 200% of the
drive rated current)
539
E5-04
(032C)
PM Mot Pole Count
Sets the number of PM motor poles.
Note:
When A1-02 = 5, 6 or 8 [OLV/PM, AOLV/PM or EZOLV], the maximum value is
48.
4
(2 - 120)
540
E5-05
(032D)
PM Mot Resistance
(Ohms/Phase)
Sets the resistance per phase of a PM motor. Set 50% of the line-to-line resistance.
0.100 Ω
(0.000 - 65.000 Ω)
540
E5-06
(032E)
PM d-Axis Inductance
(mH/Phase)
Sets the PM motor d-axis inductance.
1.00 mH
(0.00 - 300.00 mH)
540
E5-07
(032F)
PM q-Axis Inductance
(mH/Phase)
Sets the PM motor q-axis inductance.
1.00 mH
(0.00 - 600.00 mH)
540
E5-09
(0331)
PM BackEMF Vpeak
(mV/(rad/ s))
Sets the peak value of PM motor induced voltage.
0.0 mV/(rad/sec)
(0.0 - 2000.0 mV/(rad/s))
540
E5-24
(0353)
PM BackEMF L-L Vrms
(mV/rpm)
Sets the RMS value for PM motor line voltage.
200 V class: 100.0 mV/
min
-1
400 V class: 200.0 mV/
min
-1
(0.0 - 6500.0 mV/min
-1
)
541
E5-25
(035E)
Expert
Polar Est Timeout
Sets the function that switches polarity for initial polarity estimation. Usually it is not
necessary to change this setting.
0 : Disabled
1 : Enabled
0
(0, 1)
541
◆ E9: SIMPLE VECTOR SETTINGS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
E9-01
(11E4)
Motor Type Selection
Sets the type of motor.
0 : IM
1 : PM
2 : SynRM
0
(0 to 2)
541
E9-02
(11E5)
Maximum Speed
Sets the maximum speed of the motor.
Determined by E9-01
(40.0 - 120.0 Hz)
541
E9-03
(11E6)
Rated Speed
Sets the rated rotation speed of the motor.
Determined by E9-01
(100 - 7200 min
-1
)
542
E9-04
(11E7)
Base Frequency
Sets the rated frequency of the motor.
Determined by E9-01
(40.0 - 120.0 Hz)
542
E9-05
(11E8)
Base Voltage
Sets the rated voltage of the motor.
200 V Class: 200.0 V,
400 V: 400.0 V
(200 V Class: 0.0 - 255.0
V,400 V Class: 0.0 -
510.0 V)
542
E9-06
(11E9)
Motor Rated Current
Sets the motor rated current in amps.
Determined by E9-01
and o2-04
(10% to 200% of the
drive rated current)
542
E9-07
(11EA)
Motor Rated Power
(kW)
Sets the motor rated output in the units from o1-58 [Mot Capacity Unit].
Determined by E9-02
and o2-04
(0.00 - 650.00 kW)
542
E9-08
(11EB)
Motor Pole Count
Sets the number of motor poles.
4
(2 to 120)
542
