Parameter List
11
11.9 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 361
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-03
(041F)
RUN
AO An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the AO terminal at 10 V or 20 mA as 0%.
0.0%
(-999.9 - +999.9%)
620
H4-07
(0423)
AO Signal Level Select
Sets the MFAO terminal AO output signal level.
Note:
Make sure that you set jumper S5 on the control circuit terminal board when you
change these parameters.
1 : 0 to 10 Vdc
3 : 4 to 20 mA
1
(1, 3)
620
H4-20
(0B53)
An.Pwr Mon 100%
Level
Sets the level at 10 V when U1-08 [Output Power] is set for analog output.
0.00 kW
(0.00 - 650.00 kW)
620
◆ H5: MODBUS PORTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H5-01
(0425)
Mbus Address
Sets the communication slave address for drives.
Note:
• Restart the drive after changing the parameter setting.
• Setting 0 will not let the drive respond to Modbus communications.
1FH
(0 - FFH)
620
H5-02
(0426)
Mbus BaudRate
Sets the communications speed for Modbus communications.
Note:
Restart the drive after changing the parameter setting.
1 : 1200 bps
2 : 2400 bps
3 : 4800 bps
4 : 9600 bps
5 : 19.2 kbps
6 : 38.4 kbps
7 : 57.6 kbps
8 : 76.8 kbps
9 : 115.2 kbps
4
(1 - 9)
621
H5-03
(0427)
Mbus Parity
Sets the communications parity used for Modbus communications.
Note:
Restart the drive after changing the parameter setting.
1 : Even parity
2 : Odd parity
3 : No parity
1
(1 - 3)
621
H5-04
(0428)
Mbus Error Stop
Sets the motor Stopping Method when the drive detects CE [Modbus Communication
Err] issues.
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
3
(0 - 3)
621
H5-05
(0429)
Mbus Fault Detection
Selection
Sets the function that detects CE [Modbus Communication Error] issues during
Modbus communications.
0 : Disabled
1 : Enabled
1
(0, 1)
621
H5-06
(042A)
Mbus Tx Wait Time
Sets the time to wait to send a response message after the drive receives a command
message from the master.
Note:
Restart the drive after changing the parameter setting.
5 ms
(0 - 65 ms)
622
H5-09
(0435)
Mbus CE Detect Time
Sets the detection time for CE [Modbus Communication Error] issues when
communication stops.
2.0 s
(0.0 - 25.0 s)
622
H5-10
(0436)
Mbus 0025H Unit Sel
Sets the unit of measure used for the Modbus communications monitor register 0025H
(output voltage reference monitor).
0 : 0.1 V units
1 : 1 V units
0
(0, 1)
622
