10.4 Model Specifications (Single-Phase 200 V Class)
SIEPCYEUOQ2V01A Q2V Technical Manual 295
10.4 Model Specifications (Single-Phase 200 V Class)
Table 10.5 Ratings (Single-Phase 200 V Class)
Model B001 B002 B004 B006 B010 B012 B018
Maximum Applicable Motor
Output (kW)
HD
*1
0.1 0.25 0.55 1.1 1.5 2.2 4.0
ND
*2
0.2
0.18
0.37 0.75 1.1 2.2 3.0 -
Maximum Applicable Motor
Output (HP)
HD
*1
1/6 1/4 1/2 1 2 3 5
ND
*2
1/6 1/4 3/4 1.5 3 3 -
Input
Rated Input
Current (A)
HD 1.4 2.8 5.5 11 14.1 20.6
35.0
ND 2.0 5.0 7.3 13.8 20.2 24.0
-
Output
Rated Output
Capacity (kVA)
*3
HD 0.3 0.6 1.1 1.9 3 4.2 6.7
ND 0.5 0.7 1.3 2.3 3.7 4.6 -
Rated Output
Current (A)
HD 0.8 1.6 3 5 8 11
17.6
ND 1.2 1.9 3.5 6 9.6 12.2
-
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10 minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10 minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 10 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz
maximum.
Maximum Output Voltage
Single-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• V/f Control, OLVector, PM OLVector: 590 Hz
• PM AOLVector: 270 Hz
• EZ Vector: 120 Hz
Measures for
Harmonics
AC reactor External options
Braking Device Braking Transistor Standard internal characteristics
External
options
EMC Filter
EMC Filter
IEC61800-3
Category C1 (Conducted emission)
External
options
Power Supply
Rated Voltage/Rated Frequency
• Single-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
HD 0.4 0.7 1.5 2.9 3.7 5.4
9.2
ND 0.5 1.3 1.9 3.6 5.3 6.3
-
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 220 V.
