Parameter Details
12
12.10 o: KEYPAD
SIEPCYEUOQ2V01A Q2V Technical Manual 701
■ o1-58: Mot Capacity Unit
No.
(Hex.)
Name Description
Default
(Range)
o1-58
(3125)
Mot Capacity Unit
Sets the setting unit for parameters that set the motor rated power.
0
(0, 1)
The drive shows these parameter values in the set units:
• E2-11 [Motor Rated Power (kW)]
• E4-11 [M2 Rated Power (kW)]
• E5-02 [PM Mot Rated Power (kW)]
• E9-07 [Motor Rated Power (kW)]
• T1-02 [Motor Rated Power]
• T2-04 [PMMot Rated Power]
• T4-08 [Motor Rated Capacity]
0 : kW
Shows the motor output in kW units.
1 : HP
Shows the motor output in HP units.
◆ o2: KEYPAD OPERATION
■ o2-01: LO/RE Key Selection of Function
No.
(Hex.)
Name Description
Default
(Range)
o2-01
(0505)
LO/RE Key Selection of
Function
Sets the function that lets you use to switch between LOCAL and REMOTE Modes.
1
(0, 1)
0 : Disabled
You cannot use to switch between LOCAL and REMOTE Modes.
1 : Enabled
You can use to switch between LOCAL and REMOTE Modes when the drive is stopped. When LOCAL
Mode is selected, on the keypad will come on.
WARNING! Sudden Movement Hazard. If you change the control source when b1-07 = 2 [LO/RE Run Selection = Accept RUN],
the drive can start suddenly. Before you change the control source, remove all personnel from the area around the drive, motor,
and load. Sudden starts can cause serious injury or death.
WARNING! Sudden Movement Hazard. Fully examine all mechanical and electrical connections before you change o2-01 [LO/
RE Key Selection of Function] or b1-07 [LO/RE Run Selection]. Sudden starts can cause serious injury or death. If b1-07 = 2
[LO/RE Run Selection = Accept RUN] and there is an active Run command when you switch from LOCAL to REMOTE Mode,
the drive can start suddenly.
Table 12.56 Function Settings with o2-01 and b1-07
Function Selection
LOCAL/REMOTE Run Selection
Switching from LOCAL Mode to
REMOTE Mode
Switching from REMOTE Mode to
LOCAL Mode
o2-01 = 0 [Disabled] b1-07 = 1 [Cycle RUN] The drive will not switch modes. The drive will not switch modes.
b1-07 = 2 [Accept RUN]
o2-01 = 1 [Enabled] b1-07 = 1 [Cycle RUN] The drive will not start operating although
the Run command is active. When you set
Run command to active again, the drive
will start to run.
The drive cannot operate because the Run
command is not enabled.
b1-07 = 2 [Accept RUN] When the Run command is active, the
drive will start to run immediately when
the mode switches from LOCAL to
REMOTE.
The drive cannot operate because the Run
command is not enabled.
To Next Page
