12.10 o: KEYPAD
700 SIEPCYEUOQ2V01A Q2V Technical Manual
■ o1-46: 3rdMon Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-46
(11C6)
RUN
3rdMon Area Setting
Sets the horizontal axis value used to display the monitor set in o1-26 [Cust.Monitor 3] as a bar
graph. This parameter is only available when using an LCD keypad.
100.0%
(0.0 - 100.0%)
■ o1-47: Trend Plot 1 Min Scale Value
No.
(Hex.)
Name Description
Default
(Range)
o1-47
(11C7)
RUN
Trend Plot 1 Min Scale
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-24 [Cust.Monitor 1]
as a trend plot. This parameter is only available when using an LCD keypad.
-100.0%
(-300.0 - +300.0%)
■ o1-48: Trend Plot 1 Max Scale Value
No.
(Hex.)
Name Description
Default
(Range)
o1-48
(11C8)
RUN
Trend Plot 1 Max Scale
Value
Sets the horizontal axis maximum value used to display the monitor set in o1-24 [Cust.Monitor 1]
as a trend plot. This parameter is only available when using an LCD keypad.
100.0%
(-300.0 - +300.0%)
■ o1-49: Trend Plot 2 Min Scale Value
No.
(Hex.)
Name Description
Default
(Range)
o1-49
(11C9)
RUN
Trend Plot 2 Min Scale
Value
Sets the horizontal axis minimum value used to display the monitor set in o1-25 [Cust.Monitor 2]
as a trend plot. This parameter is only available when using an LCD keypad.
-100.0%
(-300.0 - +300.0%)
■ o1-50: Trend Plot 2 Max Scale Value
No.
(Hex.)
Name Description
Default
(Range)
o1-50
(11CA)
RUN
Trend Plot 2 Max Scale
Value
Sets the horizontal axis maximum value used to display the monitor set in o1-25 [Cust.Monitor 2]
as a trend plot. This parameter is only available when using an LCD keypad.
100.0%
(-300.0 - +300.0%)
■ o1-51: Trend Plot Time Scale Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-51
(11CB)
RUN
Trend Plot Time Scale
Setting
Sets the time scale (horizontal axis) to display the trend plot. When you change this setting, the
drive automatically adjusts the data sampling time. This parameter is only available when using
an LCD keypad.
300 s
(1 - 3600 s)
■ o1-55: AnGauge Area Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-55
(11EE)
RUN
AnGauge Area Selection
Sets the range used to display the monitor set in o1-24 [Custom Monitor 1] as an analog gauge.
This parameter is only available when using an LCD keypad.
1
(0, 1)
0 : + - Area (- o1-56 - o1-56 )
1 : + Area (0 - o1-56 )
■ o1-56: AnGauge Area Setting
No.
(Hex.)
Name Description
Default
(Range)
o1-56
(11EF)
RUN
AnGauge Area Setting
Sets the value used to display the monitor set in o1-24 [Cust.Monitor 1] as an analog meter. This
parameter is only available when using an LCD keypad.
100.0%
(0.0 - 100.0%)
