11.16 U: MONITORS
402 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level
U6-98
(07F8)
First Fault
Shows the contents of the most recent communication options fault (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
U6-99
(07F9)
Current Fault
Shows the contents of current fault from communication options (DeviceNet, Modbus TCP/IP,
EtherNet/IP).
No signal output available
◆ U8: Q2PACK MONITORS
No.
(Hex.)
Name Description MFAO Signal Level
U8-01 to U8-10
(1950 - 1959)
Q2pack Mon 1 to 10
Shows Q2pack Monitors 1 to 10.
Unit: 0.01%
10 V = 100%
U8-11 to U8-13
(195A - 195C)
Q2pack Ver 1 to 3
When you open the setting screen by clicking the setting button on the PC tool title bar, the user
ID can be confirmed with the ID display of the primary user.
U8-11 displays the upper, U8-12 the lower three digits of the user ID.
U8-13 displays the software ID.
No signal output available
U8-18
(1961)
Q2pack Base Platform
Shows the Q2pack platform version.
No signal output available
U8-21 to U8-25
(1964 - 1968)
Q2pack Mon 21 to 25
Shows Q2pack Monitors 21 to 25.
Unit: 0.01%
10 V = 100%
U8-31 to U8-40
(196E - 1977)
Q2pack Mon 31 to 40
Shows Q2pack Monitors 31 to 40.
Unit: 0.01%
10 V = 100%
U8-51 to U8-55
(1982 - 1986)
Q2pack Mon 51 to 55
Shows Q2pack Monitors 51 to 55.
Unit: 0.01%
10 V = 100%
