Page #608 background imageLoading...
Page #608 background image
12.7 H: TERMINALS
608 SIEPCYEUOQ2V01A Q2V Technical Manual
69: ModbusReg 2
Setting Value Function Description
69 ModbusReg 2
The terminal activates when the bit specified by H2-10 [Mbus Reg2 Bit Select] for the Modbus register address set with H2-09
[Mbus Reg2 Address Select] activates.
6A: DataLog Error
Setting Value Function Description
6A DataLog Error
The terminal activates when the drive detects LoG [Com Error / Abnormal SD card].
90 to 92: Q2pack DO1 to 3
Setting Value Function Description
90 - 92 Q2pack DO1 to 3
Sets the Q2pack digital output. Refer to the Q2pack online manual for more information.
100 to 192: Inverse output of 0 to 92
Setting Value Function Description
100 - 192 Inverse output of 0 to 92
Causes inverse output of the function for the selected MFDO. Uses the last two digits of 1xx to select which function to
inversely output.
For example, set H2-xx = 103 for the inverse output of 3 [Fault].
H3: ANALOG INPUTS
WARNING! Sudden Movement Hazard. Do test runs and examine the drive to make sure that the command references are
correct. If you set the command reference incorrectly, it can cause damage to the drive or serious injury or death.
Drives have two analog input terminals: terminals AI1 and AI2. Use H3 parameters to set the functions to these
analog input terminals and adjust signal levels.
This table shows the functions that you can set to analog input terminals. Use H3-02 and H3-10 [MFAI Function
Select] to set functions.
Table 12.47 MFAI Setting Values
Setting
Value
Function Reference
0 Through Mode 613
1 AuxFreqRef1 613
2 AuxFreqRef2 613
3 FrqBIAS Frq 613
4 Freq Ref/BIAS 613
5 Freq Gain 614
6 OutVolt Bias 614
7 TorqCompensation 614
8 TorqRef/Lim 614
9 FW Trq Lim 614
B Rev Trq Lim 616
C RegenTrqLim 616
Setting
Value
Function Reference
D GenerTrqLim 616
E OvUntrq Level 616
F PID Fbk 616
10 PID SetPoint 616
11 Diff PIDFbk 616
12 AcDcTimeGain 617
13 DCInjBrakCurr 617
14 StallPLev@Rn 617
15 OutFLowLimSel 618
16 Mot PTC Input 618
30 Q2pack AI1 618
31 Q2pack AI2 618
Note:
All analog input scaling uses gain and bias for adjustment. Set the gain and bias values correctly.
