Page #353 background image
Parameter List
11
11.9 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 353
H2: DIGITAL OUTPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H2-01
(040B)
NO,NC,CM
FuncSelection
Sets the function set for MFDO terminal NO-CM or NC-CM.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
3
(0 - 1FF)
589
H2-02
(040C)
DO1-O1C Func
Selection
Sets the function for MFDO terminal DO1-O1C.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
5
(0 - 1FF)
589
H2-03
(040D)
DO2-O2C Func
Selection
Sets the function for MFDO terminal DO2-O2C.
Note:
Set this parameter to 0 when the terminal is not being used or to use the terminal in
through mode.
F
(0 - 1FF)
589
H2-06
(0437)
kWH Out Unit Selection
Sets the unit for the output signal when H2-01 to H2-03 = 65 [MFDO Function Select
= WattH Pulse].
1 : 0.1 kWh units
2 : 1 kWh units
3 : 10 kWh units
4 : 100 kWh units
5 : 1000 kWh units
1
(1 - 5)
589
H2-07
(0B3A)
Mbus Reg1 Address
Select
Sets the address of the Modbus register output to the MFDO terminal.
0001
(0001 - 1FFF)
590
H2-08
(0B3B)
Mbus Reg1 Bit Select
Sets the bit of the Modbus register output to the MFDO terminal.
0000
(0000 - FFFF)
590
H2-09
(0B3C)
Mbus Reg2 Address
Select
Sets the address of the Modbus register output to the MFDO terminal.
0001
(0001 - 1FFF)
590
H2-10
(0B3D)
Mbus Reg2 Bit Select
Sets the bit of the Modbus register output to the MFDO terminal.
0000
(0000 - FFFF)
590
H2-20
(1540)
Compare1 Mon.
Selection
Sets the monitor number for comparator 1. Set the x-xx part of the Ux-xx [Monitor]. For
example, set H2-20 = 102 to monitor U1-02 [Output Frequency].
102
(000 - 999)
590
H2-21
(1541)
Compare1 Low Limit
Sets the lower limit detection level for comparator 1 when the full scale analog output
for the monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
590
H2-22
(1542)
Compare1 Up Limit
Sets the upper limit detection level for comparator 1 when the full scale analog output
for the monitor selected in H2-20 [Compare1 Mon.Selection] is the 100% value.
0.0%
(0.0 - 300.0%)
590
H2-23
(1543)
Compare1 Hysteresis
Sets the hysteresis level for comparator 1 as a percentage of the full scale analog output
for the monitor selected in H2-20 [Compare1 Mon.Selection].
0.0%
(0.0 - 10.0%)
591
H2-24
(1544)
Compare1 On-Delay
Time
Sets the on-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
591
H2-25
(1545)
Compare1 Off-Delay
Time
Sets the off-delay time for comparator 1.
0.0 s
(0.0 - 600.0 s)
591
H2-26
(1546)
Compare2 Mon.
Selection
Sets the monitor number for comparator 2. Set the x-xx part of the Ux-xx [Monitor]. For
example, set H2-26 = 103 to monitor U1-03 [Output Current].
103
(000 - 999)
591
H2-27
(1547)
Compare2 Low Limit
Sets the lower limit detection level for comparator 2 as a percentage of the full scale
analog output for the monitor selected in H2-26 [Compare2 Mon.Selection].
0.0%
(0.0 - 300.0%)
591
H2-28
(1548)
Compare2 Up Limit
Sets the upper limit detection level for comparator 2 as a percentage of the full scale
analog output for the monitor selected in H2-26 [Compare2 Mon.Selection].
0.0%
(0.0 - 300.0%)
591
H2-29
(1549)
Compare2 Hysteresis
Sets the hysteresis level for comparator 2 as a percentage of the full scale analog output
for the monitor selected in H2-26 [Compare2 Mon.Selection].
0.0%
(0.0 - 10.0%)
592
H2-30
(154A)
Compare2 On-Delay
Time
Sets the on-delay time for comparator 2.
0.0 s
(0.0 - 600.0 s)
592
H2-31
(154B)
Compare2 Off-Delay
Time
Sets the off-delay time for comparator 2.
0.0 s
(0.0 - 600.0 s)
592
