11.9 H: TERMINALS
354 SIEPCYEUOQ2V01A Q2V Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H2-32
(159A)
Compare1 Filter Time
Sets the time constant that is applied to the primary delay filter used for the analog
output of the monitor selected with H2-20 [Compare1 Mon.Selection].
0.0s
(0.0 - 10.0 s)
592
H2-33
(159B)
Compare1 Protection
Selection
Sets drive operation when it detects CP1 [Comparator1 Limit Fault].
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
4 : Low Speed (L8-19)
4
(0 - 4)
592
H2-34
(159C)
Compare2 Filter Time
Sets the time constant that is applied to the primary delay filter used for the analog
output of the monitor selected with H2-26 [Compare2 Mon.Selection].
0.0s
(0.0 - 10.0 s)
593
H2-35
(159D)
Compare2 Protection
Selection
Sets drive operation when it detects CP2 [Comparator2 Limit Fault].
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
4 : Low Speed (L8-19)
4
(0 - 4)
593
H2-36
(159E)
Compare1 HoldTime
Sets the length of time that CP1 [Comparator1 Limit Fault] is disabled.
0.0 s
(0.0 - 1000.0 s)
593
H2-37
(159F)
Compare2 HoldTime
Sets the length of time that CP2 [Comparator2 Limit Fault] is disabled.
0.0 s
(0.0 - 1000.0 s)
593
H2-40
(0B58)
Mbus 15E0h b0 Output
Function
Sets the MFDO for bit 0 of Modbus register 15E0 (Hex.).
F
(0 - 1FF)
593
H2-41
(0B59)
Mbus 15E0h b1 Output
Function
Sets the MFDO for bit 1 of Modbus register 15E0 (Hex.).
F
(0 - 1FF)
594
H2-42
(0B5A)
Mbus 15E0h b2 Output
Function
Sets the MFDO for bit 2 of Modbus register 15E0 (Hex.).
F
(0 - 1FF)
594
H2-60
(1B46)
Expert
NO,NC,CM 2nd
Function
Sets the second function for terminal NO/NC-CM. Outputs the logical calculation
results of the terminals assigned to functions by H2-01 [NO,NC,CM FuncSelection].
0
(0 - FF)
594
H2-61
(1B47)
Expert
NO,NC,CM Logic
Operation
Sets the logical operation for the functions set in H2-01 [NO,NC,CM FuncSelection]
and H2-60 [NO,NC,CM 2nd Function].
1
(1 - 9)
594
H2-62
(1B48)
Expert
NO,NC,CM Min ON-
Time
Sets the minimum ON time that the drive uses to output the logical calculation results
from terminal NO,NC,CM.
0.1 s
(0.0 - 25.0 s)
594
H2-63
(1B49)
Expert
DO1 2nd Function
Sets the second function for terminal DO1-O1C. Outputs the logical calculation results
of the terminals assigned to functions by H2-02 [DO1-O1C Func Selection].
o
(0 - FF)
594
H2-64
(1B4A)
Expert
DO1 Logic Operation
Sets the logical operation for the functions set in H2-02 [DO1-O1C Func Selection] and
H2-63 [DO1 2nd Function].
1
(1 - 9)
594
H2-65
(1B4B)
Expert
DO1 Min ON-Time
Sets the minimum ON time used to output the logical calculation results from terminal
DO1-O1C.
0.1 s
(0.0 - 25.0 s)
594
H2-66
(1B4C)
Expert
DO2 2nd Function
Sets the second function for terminal DO2-O2C. Outputs the logical calculation results
of the terminals assigned to functions by H2-03 [DO2-O2C Func Selection].
0
(0 - FF)
595
H2-67
(1B4D)
Expert
DO2 Logic Operation
Sets the logical operation for the functions set in H2-03 [DO2-O2C Func Selection] and
H2-66 [DO2 2nd Function].
1
(1 - 9)
595
H2-68
(1B4E)
Expert
DO2 Min ON-Time
Sets the minimum ON time used to output the logical calculation results from terminal
4NO-4CM.
0.1 s
(0.0 - 25.0 s)
595
