Parameter List
11
11.10 L: PROTECTION
SIEPCYEUOQ2V01A Q2V Technical Manual 367
No.
(Hex.)
Name Description
Default
(Range)
Ref.
L2-30
(045E)
Expert
KEB ZeroSpeed
Operation
Sets the operation when the output frequency decreases below the zero level (DC
braking injection starting frequency) during KEB deceleration when L2-01 = 1
[RideThru@PwrLoss = Enabled] and L2-50 = 2 to 4 [RidThruMode@PwrLoss = KEB
ModeKEB Stop Mode, or KEB Decel to Stop].
1 : Baseblock
2 : DC/SC Braking
1
(1, 2)
645
L2-31
(045D)
Expert
KEB StartV Offset Level
Sets the KEB start voltage offset.
Determined by A1-02
(200 V Class: 0 - 100 V,
400 V Class: 0 - 200 V)
646
◆ L3: STALL PREVENTION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
L3-01
(048F)
StallP Mode@Accel
Sets the method of the Stall Prevention During Acceleration.
1 : Disabled
2 : General Purpose
3 : Intelligent Accel
4 : ILim Mode
2
(1 - 4)
647
L3-02
(0490)
StallP Level@Accel
Sets the output current level at which the Stall Prevention function operates during
acceleration where the drive rated output current is 100%.
Note:
The upper limit to the setting range changes when the setting for C6-01 [ND/HD
Duty Selection] changes.
• 150% when C6-01 = 0 [HD Rating]
• 120% when C6-01 = 1 [ND Rating]
Determined by C6-01
and L8-38
(0 - 150%)
649
L3-03
(0491)
StallP Limit@Accel
Sets the lower limit for the stall prevention level used in the constant output range as a
percentage of the drive rated output current.
50%
(0 - 100%)
649
L3-04
(0492)
StallP@Decel Enable
Enables Stall Prevention during deceleration.
0 : Disabled
1 : Enabled
1
(0, 1)
649
L3-50
(0458)
StallP@Decel Mode
Sets the method that the drive will use to prevent overvoltage faults when decelerating.
Note:
1. To connect a dynamic braking option (braking resistor or braking resistor unit)
to the drive, set this parameter to 0 or 3. Parameter values 1, 2, 4, and 5 will
enable Stall Prevention function during deceleration, and the dynamic braking
option will not function.
2. The setting range changes when the A1-02 [Control Method] value changes:
• When A1-02 = 5 [PM OLVector], setting range is 0 to 2
• When A1-02 = 6, or 8 [PM AOLVector, or EZ Vector], setting range is 0, 1.
0 : General Purpose
1 : Automatic Decel Reduction
2 : Gen Purpose w/ DB Resistor
3 : HiFlux Overexcitation
4 : HiFlux2 Overexcitation
0
(Determined by A1-02)
654
L3-05
(0493)
StallP@RUN Enable
Enables Stall Prevention during Run.
Note:
• An output frequency less than 6 Hz disables Stall Prevention during Run. The
setting values of L3-05 and L3-06 [StallP Level@Run] do not have an effect.
• The setting range changes when the A1-02 [Control Method] value changes:
–A1-02 = 0, 5 [V/f Control, PM OLVector] : 0 to 2
–A1-02 = 8 [EZ Vector] : 0, 3
0 : Disabled
1 : Enabled
Determined by A1-02
(0 - Determined by A1-
02)
650
L3-51
(0459)
StallP@RUNDecTime
Sets the function to enable and disable Stall Prevention During Run.
Note:
An output frequency less than 6 Hz will disable Stall Prevention during Run
regardless of L3-05 and L3-06 [StallP Level@Run] settings.
0 : Dec Time 1 (C1-02)
1 : Dec Time 2 (C1-04)
0
(Determined by A1-02)
655
