10.8 Drive Models and Drive Watt Loss
304 SIEPCYEUOQ2V01A Q2V Technical Manual
10.8 Drive Models and Drive Watt Loss
◆ Drive Watt Loss
■ Three-Phase 200 V Class
Table 10.18 Drive Watt Loss (HD, Fc = 2 kHz)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2001 0.8 2 7 4 11
2002 1.6 2 8 7 15
2004 3.0 2 12 13 25
2006 5.0 2 20 22 42
2008 ?? 2 ?? ?? ??
2010 8.0 2 18 37 55
2012 11.0 2 24 49 73
2018 ?? 2 ?? ?? ??
2021 17.6 2 37 83 120
2030 25.0 2 46 163 209
2042 33.0 2 56 200 256
2056 47.0 2 78 269 347
2070 60.0 2 109 411 520
2082 75.0 2 133 439 572
Table 10.19 Drive Watt Loss (HD, Fc = Default Setting)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2001 1.2 10 7 5 12
2002 1.9 10 8 8 16
2004 3.5 10 13 16 29
2006 6 10 21 27 48
2008 ?? 8 ?? ?? ??
2010 9.6 8 19 43 62
2012 12.2 8 25 56 81
2018 ?? 8 ?? ?? ??
2021 21 8 41 108 149
2030 30 8 50 187 237
2042 42 8 61 232 293
2056 56 8 86 318 404
2070 70 8 120 473 593
2082 82 8 149 525 674
■ Single-Phase 200 V Class
Table 10.20 Drive Watt Loss (HD, Fc = 2 kHz)
Model
Rated output current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 0.8 2 8 4 12
B002 1.6 2 12 7 19
B004 3 2 17 13 30
B006 5 2 20 23 43
