12.2 b: APPLICATION
SIEPCYEUOQ2V01A Q2V Technical Manual 483
When the drive accelerates to the output frequency set in b6-01, it holds that frequency for the time set in b6-02
[Dwell Time@Start], and starts to accelerate again.
■ b6-02: Dwell Time@Start
No.
(Hex.)
Name Description
Default
(Range)
b6-02
(01B7)
Dwell Time@Start
Sets the length of time that the drive will hold the output frequency when the motor starts.
0.0 s
(0.0 - 10.0 s)
■ b6-03: Dwell Ref@Stop
No.
(Hex.)
Name Description
Default
(Range)
b6-03
(01B8)
Dwell Ref@Stop
Sets the output frequency that the drive will hold momentarily when ramping to stop the motor.
0.0
(Determined by A1-02)
When the drive decelerates to the output frequency set in b6-03, it holds that frequency for the time set in b6-04
[Dwell Time@Stop] and starts to decelerate again.
■ b6-04: Dwell Time@Stop
No.
(Hex.)
Name Description
Default
(Range)
b6-04
(01B9)
Dwell Time@Stop
Sets the length of time for the drive to hold the output frequency when ramping to stop the motor.
0.0 s
(0.0 - 10.0 s)
◆ b8: ENERGY SAVING
Energy-saving control improves overall system operating efficiency by operating the motor at its most efficient
level.
Set b8-01 and these parameters according to the control method and the motor.
• When you use V/f Control, set parameters b8-04 to b8-06.
• When you use vector control with an induction motor, set parameters b8-02 and b8-03.
• When you use a PM motor, set parameters b8-16 and b8-17.
Note:
• Energy-saving control is not appropriate for applications with sudden changes in the load, or applications driving heavy loads such as a
traverse car application.
• Energy-saving control maximizes operation based on precise motor data set to the drive. Make sure that you do Auto-Tuning and enter
the correct information about the motor before you use the Energy-saving control.
■ b8-01: eSave Ctrl Selection
No.
(Hex.)
Name Description
Default
(Range)
b8-01
(01CC)
eSave Ctrl Selection
Sets the Energy-saving control function.
0
(0 - 2)
0 : Disabled
1 : Enabled
2 : Search Enabled
Note:
When A1-02 = 6 [Control Method = PM AOLVector], you can only select setting 2 in Expert Mode.
■ b8-02: eSave Ctrl Gain
No.
(Hex.)
Name Description
Default
(Range)
b8-02
(01CD)
RUN
Expert
eSave Ctrl Gain
Sets the gain for Energy-saving control.
Determined by A1-02
(0.0 - 10.0)
Increase the setting value to increase energy saving. If the setting value is too large, the motor will stall.
