12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 595
■ H2-66: DO2 2nd Function
No.
(Hex.)
Name Description
Default
(Range)
H2-66
(1B4C)
Expert
DO2 2nd Function
Sets the second function for terminal DO2-O2C. Outputs the logical calculation results of the
terminals assigned to functions by H2-03 [DO2-O2C Func Selection].
0
(0 - FF)
■ H2-67: DO2 Logic Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-67
(1B4D)
Expert
DO2 Logic Operation
Sets the logical operation for the functions set in H2-03 [DO2-O2C Func Selection] and H2-66
[DO2 2nd Function].
1
(1 - 9)
Refer to Output of Logical Operation Results of MFDO on page 588 for more information about the relation
between parameter settings and logical operations.
■ H2-68: DO2 Min ON-Time
No.
(Hex.)
Name Description
Default
(Range)
H2-68
(1B4E)
Expert
DO2 Min ON-Time
Sets the minimum ON time used to output the logical calculation results from terminal DO2-O2C.
0.1 s
(0.0 - 25.0 s)
◆ MFDO Setting Value
Selects the function configured to a MFDO.
■ 0: Through Mode
Setting Value Function Description
0 Through Mode
Use this setting for unused terminals or to use terminals in through mode. Also use this setting as the PLC contact output via
Modbus or the communication option. This signal does not function if signals from the PLC are not configured.
■ 1: Drive Ready
Setting Value Function Description
1 Drive Ready
The terminal activates when the drive is ready and running.
The terminal deactivates in these conditions:
• When the power supply is OFF
• During a fault
• When there is problem with the control power supply
• When there is a parameter configuration error and the drive cannot operate although there is a Run command
• When you enter a Run command and it immediately triggers an overvoltage or undervoltage fault because the
drive has an overvoltage or undervoltage fault during stop
• When the drive is in Programming Mode and will not accept a Run command
■ 2: Drive Enable
Setting Value Function Description
2 Drive Enable
This terminal activates when the H1-xx = 1A [Drive Enable] terminal activates.
■ 3: Fault
Setting Value Function Description
3 Fault
The terminal activates when the drive detects a fault.
