Mechanical Installation
2
2.8 Installation Methods
SIEPCYEUOQ2V01A Q2V Technical Manual 37
2.8 Installation Methods
The drive installation methods include standard installation and external heatsink installation.
◆ Standard Installation
Refer to Drive Exterior and Mounting Dimensions on page 307 for more information about external dimensions.
◆ External Heatsink
The optional External Heatsink Installation Kit will let you install the drive with the heatsink external to the
enclosure panel.
This table shows the model number for the attachment. Contact the manufacturer or your nearest sales
representative to order mounting brackets and mounting hardware.
Table 2.1 External Heatsink Installation Kit
Drive Model Model
2001
ZPSA-GA50V1-1
2002
2004 ZPSA-GA50V1-2
2006 ZPSA-GA50V1-3
2008
ZPSA-GA50V2-32010
2012
2018
ZPSA-GA50V3-1
2021
2030
ZPSA-GA50V5-1
2042
2056 ZPSA-GA50V6-1
2070
ZPSA-GA50V7-1
2082
B001
ZPSA-GA50V1-1
B002
B004 ZPSA-GA50V1-2
Drive Model Model
B006 ZPSA-GA50V2-2
B010 ZPSA-GA50V2-3
B012 ZPSA-GA50V3-1
B018 ZPSA-GA50V4-1
4001 ZPSA-GA50V2-1
4002
ZPSA-GA50V2-2
4004
4005
ZPSA-GA50V2-34007
4009
4012 ZPSA-GA50V3-1
4018
ZPSA-GA50V5-1
4023
4031
ZPSA-GA50V6-1
4038
4044
ZPSA-GA50V8-1
4060
