11.10 L: PROTECTION
SIEPCYEUOQ2V01A Q2V Technical Manual 369
◆ L4: SPEED DETECTION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
L4-01
(0499)
SpAgree Det.Level
Sets the level to detect speed agree or motor speed.
Sets the level to detect speed agree or motor speed when H2-01 to H2-03 = F, 10, 13,
14 [NO,NC,CM FuncSelection to DO2-O2C Func Selection = SpeedAgree1,
USpeedAgree1, FreqDetect 1, FreqDetect 2].
Determined by A1-02
(Determined by A1-02)
656
L4-02
(049A)
SpAgree Det.Width
Sets the width to detect speed agree or motor speed.
Sets the width to detect speed agree or motor speed when H2-01 to H2-03 = F, 10, 13,
14 [NO,NC,CM FuncSelection to DO2-O2C Func Selection = SpeedAgree1,
USpeedAgree1, FreqDetect 1, FreqDetect 2].
Determined by A1-02
(Determined by A1-02)
656
L4-03
(049B)
SpAgree Det.Level(+/-)
Sets the level to detect speed agree or motor speed.
Sets the level to detect speed agree or motor speed when H2-01 to H2-03 = 11, 12, 15,
16 [NO,NC,CM FuncSelection to DO2-O2C Func Selection = SpeedAgree2,
USpeedAgree2, FreqDetect 3, FreqDetect 4].
Determined by A1-02
(Determined by A1-02)
656
L4-04
(049C)
SpAgree Det.Width(+/-)
Sets the width to detect speed agree or motor speed.
Sets the width to detect speed agree or motor speed when H2-01 to H2-03 = 11, 12, 15,
16 [NO,NC,CM FuncSelection to DO2-O2C Func Selection = SpeedAgree2,
USpeedAgree2, FreqDetect 3, FreqDetect 4].
Determined by A1-02
(Determined by A1-02)
656
L4-05
(049D)
FrefLoss Det.Selection
Sets the operation when the drive detects a loss of frequency reference.
1 : Stop
2 : Run@L4-06PrevRef
1
(1, 2)
656
L4-06
(04C2)
Freq.Ref@RefLoss
Sets the frequency reference as a percentage to continue drive operation after it detects a
frequency reference loss. The value is a percentage of the frequency reference before
the drive detected the loss.
80.0%
(0.0 - 100.0%)
657
L4-07
(0470)
SpAgree Det.Selection
Sets the condition that activates speed detection.
1 : No Detect@BB
2 : Always Detect
1
(1, 2)
657
L4-08
(047F)
Sp Agree Source
Selection
Sets the drive to use the soft starter output frequency or the motor speed (estimation
value) for speed detection.
0 : SFS O/P (Reference)
1 : MotSpd (ActSpeed)
1
(0, 1)
657
◆ L5: FAULT RESTART
No.
(Hex.)
Name Description
Default
(Range)
Ref.
L5-01
(049E)
Auto-Reset Attempts
Sets the number of times that the drive will try to restart.
0
(0 - 10 times)
658
L5-02
(049F)
Fault@Reset Select
Sets the function that sends signals to the MFDO terminal set for Fault [H2-xx = 3]
while the drive is automatically restarting.
1 : Disable Fault Output
2 : Enable Fault Output
1
(1, 2)
659
L5-04
(046C)
Interval Reset Time
Sets the time interval between each Auto Restart attempt. This function is enabled when
L5-05 = 2 [Reset Method = Use L5-04 Time].
10.0 s
(0.5 - 600.0 s)
659
L5-05
(0467)
Reset Method
Sets the count method for the Auto Restart operation.
1 : Continuous
2 : Use L5-04 Time
1
(1, 2)
659
