Parameter Details
12
12.7 H: TERMINALS
SIEPCYEUOQ2V01A Q2V Technical Manual 569
■ H1-26: DI6 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-27
(0B76)
DI7 Funct.Sel 2
Sets the second function for MFDI terminal DI7.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI6 activates, it will operate the function set to H1-06 [DI6 Function Selection] and the
function set to H1-26 at the same time.
When the setting value is 0, the function is disabled.
■ H1-27: DI7 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-27
(0B76)
DI7 Funct.Sel 2
Sets the second function for MFDI terminal DI7.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI7 activates, it will operate the function set to H1-07 [DI7 Function Selection] and the
function set to H1-27 at the same time.
When the setting value is 0, the function is disabled.
■ Modbus MFDI 1 to 3 Function Selection
You can set the function for the MFDI to Modbus register bit 0 to 2 of [15C0(Hex.)]. Use H1-40 to H1-42 [Mbus
15C0h b0 Input Function to Mbus 15C0h b2 Input Function] to select the function.
Note:
• Refer to H1: DIGITAL INPUTS on page 566 for more information on the virtual digital input setting values.
• You cannot set values 5 [3-Wire Seq.] and 20 to 2F [External Fault] for H1-40 to H1-42.
• When you will not useH1-40 to H1-42, set them to 0 [Through Mode].
■ H1-40: Mbus 15C0h b0 Input Function
No.
(Hex.)
Name Description
Default
(Range)
H1-40
(0B54)
Mbus 15C0h b0 Input
Function
Selects MFDI function assigned to bit 0 of the Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
■ H1-41: Mbus 15C0h b1 Input Function
No.
(Hex.)
Name Description
Default
(Range)
H1-41
(0B55)
Mbus 15C0h b1 Input
Function
Selects MFDI function assigned to bit 1 of the Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
■ H1-42: Mbus 15C0h b2 Input Function
No.
(Hex.)
Name Description
Default
(Range)
H1-42
(0B56)
Mbus 15C0h b2 Input
Function
Selects MFDI function assigned to bit 2 of the Modbus register 15C0 (Hex.).
0
(1 - 4, 6 - 19F)
◆ MFDI Setting Values
Selects a function set with H1-01 to H1-07.
■ 0: Through Mode
Setting Value Function Description
0 Through Mode
Use this setting for unused terminals or to use terminals in through mode.
Through Mode uses the signal input to the terminal as a digital input for the upper sequence through a
communication option or Modbus communications. This input signal does not have an effect on drive operation.
To Next Page
