11.17 Parameters that Change from the Default Settings with A1-02 [Control Method]
SIEPCYEUOQ2V01A Q2V Technical Manual 403
11.17 Parameters that Change from the Default Settings with
A1-02 [Control Method]
The values for the parameters in these tables depend on the values for parameter A1-02. When you change the
setting for A1-02, the default settings will change.
Table 11.1 A1-02 = 0, 2 [V/f Control, OLVector]
No. Name Range Unit
Control Method (A1-02 Setting)
V/f
(0)
OLV
(2)
b2-01 ZSpd/DCI Threshold 0.0 - 10.0 0.1 Hz 0.5 0.5
b2-04 DCInj Time@Stop 0.00 - 10.00 0.01 s 0.50 0.50
b3-01 SpSrch@Start Selection 0 - 1 1 0 0
b3-02
SpSrch Deactivation
Current
0 - 200 1% 120 100
b3-08
Speed ACR PGain for
Estimation
0.00 - 6.00 0.01 0.50
*1
0.50
*1
b3-09
Speed ACR ITime for
Estimation
0.0 - 1000.0 0.1 ms 2.0 2.0
b3-14
Speed Bi-Directional
Search
0 - 1 1 0 0
b5-15 Sleep Start Level 0.0 - 400.0 0.1 Hz 0.0 0.0
b6-01 Dwell Ref.@Start 0.0 - 400.0 0.1 Hz 0.0 0.0
b6-03 Dwell Ref@Stop 0.0 - 400.0 0.1 Hz 0.0 0.0
b8-02 eSave Ctrl Gain 0.0 - 10.0 0.1 - 0.7
b8-03 eSave Filter Time 0.00 - 10.00 0.01 s - 0.50
b8-19 eSave Search Frequency 10 - 300 1 Hz 100 100
C1-11 Ac/Dec Switch Frequency 0.0 - 400.0 0.1 Hz 0.0 0.0
C2-01 Jerk@Start of Accel 0.00 - 10.00 0.01 s 0.20 0.20
C3-01 Slip Comp Gain 0.0 - 2.5 0.1 0.0 1.0
C3-02 Slip Comp Delay Time 0 - 10000 1 ms 2000 200
C4-01 Trq Comp Gain 0.00 - 2.50 0.01 1.00 1.00
C4-02 Trq Comp Delay Time 0 - 10000 1 ms 200 20
C5-01 ASR PGain 1 0.00 - 300.00 0.01 - -
C5-02 ASR ITime 1 0.000 - 60.000 0.001 s - -
C5-03 ASR PGain 2 0.00 - 300.00 0.01 - -
C5-04 AASR ITime 2 0.000 - 10.000 0.001 s - -
C5-06 ASR Delay Time 0.000 - 0.500 0.001 s - -
C5-07
ASR Gain Switch
Frequency
0.0 - 400.0 0.1 Hz 0.0Hz 0.0Hz
C6-02
Carrier Frequency
Selection
1 - F 1 1
*2
1
*2
d3-01 Jump Frequency 1 0.0 - 400.0 0.1 Hz 0.0 0.0
d3-02 Jump Frequency 2 0.0 - 400.0 0.1 Hz 0.0 0.0
d3-03 Jump Frequency 3 0.0 - 400.0 0.1 Hz 0.0 0.0
d3-04 Jump Frequency Width 0.0 - 20.0 0.1 Hz 1.0 1.0
E1-04 Max Output Frequency 40.0 - 400.0
*2 *3
0.1 Hz 60.0
*4
60.0
E1-05 Max Output Voltage 0.0 - 255.0
*5
0.1 V 200.0
*4
200.0
E1-06 Base Frequency 0.0 - 400.0
*3
0.1 Hz 60.0
*4
60.0
E1-07 Mid A Frequency 0.0 - 400.0
*3
0.1 Hz 3.0
*4
3.0
E1-08 Mid AVoltage 0.0 - 255.0
*5
0.1 V 15.0
*4
11.0
E1-09 Min Output Frequency 0.0 - 400.0
*3
0.1 Hz 1.5
*4
0.5
