10.3 Model Specifications (Three-Phase 200 V Class)
292 SIEPCYEUOQ2V01A Q2V Technical Manual
10.3 Model Specifications (Three-Phase 200 V Class)
Table 10.2 Ratings (Three-Phase 200 V Class)
Model 2001 2002 2004 2006
Maximum Applicable Motor Output (kW)
HD
*1
0.1 0.25 0.55 1.1
ND
*2
0.18 0.37 0.75 1.1
Maximum Applicable Motor Output (HP)
HD
*1
1/6 1/4 1/2 1
ND
*2
1/6 1/4 3/4 1.5
Input
Rated Input Current
(A)
HD 0.7 1.5 2.9 5.8
ND 1.1 1.9 3.9 7.3
Output
Rated Output
Capacity (kVA)
*3
HD 0.3 0.6 1.1 1.9
ND 0.5 0.7 1.3 2.3
Rated Output
Current (A)
HD 0.8 1.6 3.0 5.0
ND 1.2 1.9 3.5 6
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 10 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• EZ Vector: 120 Hz
• PM AOLVector: 270 Hz
• V/f Control, OLVector, PM OLVector: 590 Hz
Measures for
Harmonics
DC reactor External options
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3
Category C3 (Conducted emission)
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power (kVA)
HD 0.3 0.7 1.3
2.7
ND 0.5 1.2 1.8
3.3
Table 10.3 Ratings (Three-Phase 200 V Class)
Model 2008
2010 2012
2018 2021
Maximum Applicable Motor Output (kW)
HD
*1
1.1 1.5 2.2 3 4.0
ND
*2
1.5 2.2 3 3.7 5.5
Maximum Applicable Motor Output (HP)
HD
*1
1.5 2 3 4 5
ND
*2
2 3 4 5 5
Input
Rated Input Current
(A)
HD 7.0 7.5 11 15.6 18.9
ND 8.8 10.8 13.9 18.5 24
