Specifications
10
10.3 Model Specifications (Three-Phase 200 V Class)
SIEPCYEUOQ2V01A Q2V Technical Manual 293
Model 2008
2010 2012
2018 2021
Output
Rated Output
Capacity (kVA)
*3
HD 2.6 3 4.2 5.3 6.7
ND 3 3.7 4.6 6.7 8
Rated Output
Current (A)
HD 6.9 8.0 11.0 14.0 17.6
ND 8 9.6 12.2 17.5 21
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every
10 minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every
10 minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• V/f Control, OLVector, PM OLVector: 590 Hz
• PM AOLVector: 270 Hz
• EZ Vector: 120 Hz
Measures for
Harmonics
DC reactor External options
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3
Category C3 (Conducted emission)
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power (kVA)
HD
3.2 3.4 5.0 7.1 8.7
ND
4.0 4.9 6.4 8.5 11
Table 10.4 Ratings (Three-Phase 200 V Class)
Model
2030 2042 2056 2070 2082
Maximum Applicable Motor Output (kW)
HD
*1
5.5 7.5 11 15 18.5
ND
*2
7.5 11 15 18.5 22
Maximum Applicable Motor Output (HP)
HD
*1
7.5 10 15 20 25
ND
*2
10 10 20 25 30
Input
Rated Input Current
(A)
HD 24 37 52 68 96
ND 37 52 68 80 114
To Next Page
