Parameter List
11
11.8 F: OPTIONS
SIEPCYEUOQ2V01A Q2V Technical Manual 341
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F1-11
(038A)
Speed Dev Delay Time
Sets the length of time that the difference between the frequency reference and speed
feedback must be more than the level in F1-10 to cause dEv [Speed Deviation].
Note:
When A1-02 = 0 [Control Method = V/f Control], set H6-01 = 3 [PI Pulse Train
Function = PG Feedback] to enable this parameter.
0.5 s
(0.0 - 10.0 s)
546
F1-14
(038D)
Enc PGOpen Time for
Detection
Sets the length of time that the drive must not receive a pulse signal to cause PGo
[Encoder (PG) Feedback Loss].
Note:
Motor speed and load conditions can cause ov [Overvoltage] and oC [Overcurrent]
faults.
When A1-02 = 0 [Control Method = V/f Control], set H6-01 = 3 [PI Pulse Train
Function = PG Feedback] to enable this parameter.
2.0 s
(0.0 - 10.0 s)
546
F6: COMMUNICATIONS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-01
(03A2)
Comm.Error Selection
Sets the method to stop the motor or let the motor continue operating when the drive
detects bUS [Option Communication Error].
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
4 : AL-Run at d1-04
5 : AL-Ramp Stop
1
(0 - 5)
551
F6-02
(03A3)
Comm Ext Flt Detect
(EF0)
Sets the conditions at which EF0 [Option Card External Fault] is detected.
0 : Always Detected
1 : Detect@RUN Only
0
(0, 1)
551
F6-03
(03A4)
Comm Ext Flt Select
(EF0)
Sets the method to stop the motor or let the motor continue operating when the drive
detects EF0 [Option Card External Fault].
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
1
(0 - 3)
552
F6-04
(03A5)
bUS Err Det.Time
Sets the delay time for the drive to detect bUS [Option Communication Error].
Note:
When you install an option card in the drive, the parameter value changes to 0.0 s.
2.0 s
(0.0 - 12.0 s)
552
F6-06
(03A7)
Trq Lim Com Option
Sets the function that enables and disables the torque reference and torque limit
received from the communication option.
0 : Disabled
1 : Enabled
0
(0, 1)
552
F6-07
(03A8)
Multi-Ref@NetRef/
ComRef
Sets the function that enables and disables the multi-step speed reference when the
freqency reference source is NetRef or ComRef (communication option card or Modbus
communications).
0 : Disable MultiStep References
1 : Enable MultiStep References
1
(0, 1)
552
F6-08
(036A)
Comm Par
RST@Initialize
Sets the function to initialize F6-xx and F7-xx parameters when the drive is initialized
with A1-03 [Initialize Parameters].
0 : Retain Pars - No Reset
1 : Factory Default - Reset
0
(0, 1)
553
F6-10
(03B6)
CCLink Node Address
Sets the node address for CC-Link communication. Restart the drive after you change
the parameter setting.
Note:
Be sure to set a node address that is different than all other node addresses. Do not
set this parameter to 0. Incorrect parameter settings will cause AEr [Station Address
Setting Error] errors and the L.ERR LED on the option will come on.
0
(0 - 64)
553
